Product Name : Weighbridges


...
  • Soft Touch Tactile Switches
  • Quick Response Time
  • Tare Facility with Zero Function
  • LED Display
  • ABS Body
  • Easy to Operate, Compact Design
  • Over load protection
  • Weather & water proof sophisticated tactile keyboard
  • High accurate load cell
  • Approved by Weight & Measurement Dept. Govt. of West Bengal.
  • 12 to 15 w power consumption.
  • 230 V ± 10% 50Hz volts AC.
  • 2Operating Temperature Range 0°C to 50°C
  • Extra/Remote Display
  • Printer/Rs232 Interface/Cabinet/Wind shield
MODEL CAPACITY E VALUE PLATFORM SIZE (mm)
ATWB 25MT 5kg 7.5 X 3 OR 9 X 3
30MT 5kg 7.5 X 3 OR 9 X 3
40MT 5kg 7.5 X 3 OR 9 X 3 OR 12 X 3
50MT 5kg 7.5 X 3 OR 9 X 3 OR 12 X 3
60MT 10kg 12 X 3 OR 15 X 3
80MT 10kg 16 X 3 OR 18 X 3
100MT 10kg 16 X 3 OR 18 X 3 OR 20 X 3 OR 24 X 3td
CUSTOMISED - - -
